Benefits: OmniAccess ESR Modular Routers

• 800 MHz dual core CPU provides full routing functionality and leaves a core available for applications.
• Simplifies application management in offices, by integrating it into the same box as the router.
• One of the most complete network protocol stacks for access routers Worldwide
• Very high performance.
• Top-grade management. The SNMPv3 agent allows integration with network management platforms.
• Embedded WLAN IEEE 802.11a/b/g/n interface (MIMO, double port for external WiFi antennas), with professional security (IEEE 802.11i).
• Embedded 4G cellular interface

Features: OmniAccess ESR Modular Routers

State of the art in hardware and software

Up to two independent devices perfectly integrated into one box:

• Powerful modular router with advanced routing functionality
• Versatile applications server with a Debian GNU/Linux base

Secure Communications

• Encryption processor incorporated; optimizes device performance in scenarios with IPSec tunnels.
• Fully parameterized IPSec Client/Server.  Advanced IPSec features such as PKI encryption (Digital Certificates), extended authentication and Reverse-Route Injection guaranteeing compatibility with other commercial VPN solutions.
• Latest generation meshed topology VPN networks (Dynamic Multipoint VPN technology).

Modularity

• Base double connectivity Gigabit and an 8 port integrated switch (with optional PoE)
• 2 expansion slots and many card possibilities: VDSL2, ADSL2+, G.SHDSL (2p), 3 serial ports, 2 BRI, 2 SFP, 4 FXS/FXO, 2 E&M, or 4 E1/T1.

Routing software orientated towards enterprises

The OmniAccess 5800 series uses ESR code (Alcatel-Lucent’s Internetworking Code), and is widely regarded as a point of reference for professional routing and used by the hundreds of thousands of devices operating for clients and in the most demanding environments. The following are just a few of the outstanding characteristics:

• Enormous emphasis is placed on security, incorporating firewall features (Stateful firewall) and IPSec with all its variants (RC4, DES, 3DES, RSA, SHA-1, MD5 algorithms, digital certificates, DMVPN, GETVPN, etc…)
• Supports IP Telephony with Media Gateway features (MGCP, SIP, H323) and IP Telephony integrated server capable of managing up to 300 telephones with SIP, H323, Alcatel NOE/UE or SCCP (Skinny) protocols.
• Quality of Service, with CBWFQ, LLQ and WRED algorithms supporting hierarchical system with 32 different traffic classes per interface, traffic marking and profiling as well as traffic pre-classification contained in VPNs and integrating QoS with MPPP and fragmentation.
• Necessary routing protocols adapted to corporate networks and MPLS in general (RIP-2, BGP-4 and OSPF in addition to Policy Routing, routing activating based on polls, HSRP, VRRP, VRF,…)
• Management adapted to needs of carriers and large enterprises through powerful command lines (CLI), access controlled through RADIUS/TACACS+, SNMPv3, ample level of debugs and statistics, integrated analyzer compatible with Ethereal/Wireshark, etc.

Application scenarios on the embedded GNU/Linux core

As an applications server, the OmniAccess 5800 series can be integrated in numerous scenarios such as:

• intrusion detection polls and service denegation
• communications accelerator
• web cache proxy and content control
• file or printer server
• video flow control,
• digital signage
• domotics
• energy efficiency
